ASUS TUF B550M-PLUS Gaming Motherboard (AMD AM4, mATX, DDR4, PCIe 4.0, USB 3.2, 2.5G LAN)
Product Description
The ASUS TUF GAMING B550M-PLUS is a durable and high-performance Micro-ATX motherboard designed for AMD Ryzen processors (AM4 socket). Built for gamers and power users, it features 4x DDR4 slots (up to 128GB RAM), PCIe 4.0 support, USB 3.2 Gen 2, and military-grade durability. With robust power delivery, advanced cooling, and multiple connectivity options (M.2 NVMe, 2.5G LAN, HDMI/DP), this motherboard ensures stability and speed for gaming and multitasking.
Key Features
✔ AMD AM4 Socket – Supports AMD Ryzen 5000, 4000, and 3000 series CPUs.
✔ 128GB DDR4 RAM – Dual-channel, up to 4400MHz (OC) for high-speed performance.
✔ PCIe 4.0 Ready – Faster GPU and NVMe SSD speeds.
✔ 2.5G LAN & USB 3.2 Gen 2 – High-speed wired networking and data transfer.
✔ Military-Grade Durability – Reinforced components for long-term reliability.
✔ Comprehensive Cooling – Multiple fan headers and VRM heatsinks.
✔ M.2 NVMe Support – Ultra-fast storage options.
Technical Specifications
Model : ASUS TUF GAMING B550M-PLUS Form Factor : Micro-ATX (24.4cm x 24.4cm) CPU Socket : AMD AM4 (Ryzen 5000/4000/3000) Chipset : AMD B550 Memory Support : 4x DDR4 DIMMs, Up to 128GB, Dual-Channel Memory Speed : 2133MHz – 4400MHz (OC) Expansion Slots : 1x PCIe 4.0 x16, 1x PCIe 3.0 x16, 2x PCIe 3.0 x1 Storage : 6x SATA, 2x M.2 (PCIe 4.0 & SATA) USB Ports : USB 3.2 Gen 2 (Type-C), USB 3.1, USB 2.0 Video Outputs : HDMI, DisplayPort (varies by CPU) Networking : Realtek 2.5G Ethernet Audio : Realtek ALC887 7.1-Channel HD Audio Power Connector : 24-pin ATX + 8-pin EPS Cooling : Multiple fan headers, VRM heatsinks BIOS : UEFI BIOS with AI Tweaker Warranty : 3 Years
Package Contents
-
ASUS TUF GAMING B550M-PLUS Motherboard
-
User Manual
-
I/O Shield
-
SATA Cables
-
M.2 Screws
Compatibility & Notes
-
CPU Support: AMD Ryzen 5000/4000/3000 Series (Requires BIOS update for Ryzen 5000).
-
Graphics: Requires a dedicated GPU (no integrated graphics unless using Ryzen APUs).
-
OS Support: Windows 10/11 (64-bit).
-
